Key Specifications
- Output Power: 525W
- Efficiency: 23.2%
- First – year Degradation: ≤1%
- Annual Degradation from Year 2 – 30: ≤0.35%
30 – year Linear Performance Warranty
The graph shows a gradual decline in module performance over 30 years. Starting from 100% at the beginning, it decreases to a certain percentage at the end of the 30 – year period.
Electrical Characteristics (STC: AM1.5 1000W/m² 25°C; NOCT: AM1.5 800W/m² 20°C 1m/s)
| Module Type | Test Conditions | Pmax [W] | Voc [V] | Vmp [V] | Isc [A] | Imp [A] | Module Efficiency |
|---|---|---|---|---|---|---|---|
| AIKO – A500 – MAH60Mb | STC | 500 | 45.02 | 37.90 | 14.05 | 13.02 | 22.6% |
| NOCT | 379 | 42.71 | 35.96 | 11.35 | 10.55 | – | |
| AIKO – A505 – MAH60Mb | STC | 505 | 45.12 | 38.00 | 14.11 | 13.30 | 22.8% |
| NOCT | 383 | 42.80 | 36.05 | 11.40 | 10.65 | – | |
| AIKO – A510 – MAH60Mb | STC | 510 | 45.22 | 38.10 | 14.17 | 13.39 | 23.0% |
| NOCT | 386 | 42.90 | 36.15 | 11.45 | 10.70 | – | |
| AIKO – A515 – MAH60Mb | STC | 515 | 45.32 | 38.20 | 14.23 | 13.49 | 23.2% |
| NOCT | 390 | 42.99 | 36.24 | 11.49 | 10.78 | – |
Product Specification
- Cell Type: N – Type ABC
- Glass: 3.2 mm tempered glass
- Backsheet: High weather resistant backsheet
- Frame: Black Anodized aluminum
- Cable: 4mm²(IEC) 12AWG(UL) ±1200mm
- No. of Cells: 120(6*20)
- Junction Box: IP68, 3 bypass diodes
- Connector: MC4 – Evo2
- Weight: 23.1kg±5%
- Dimension: 1954113430mm
- Package Detail: 37pcs per pallet / 185pcs per 20’GP / 888pcs per 40’HC
Temperature Ratings (STC)
- Temperature Coefficient of Isc: + 0.05%/ °C
- Temperature Coefficient of Voc: – 0.22%/ °C
- Temperature Coefficient of Pmax: – 0.26%/ °C
Installation Guide
- Operation Temperature: -40°C – +85°C
- Maximum Series Fuse Rating: 25A
- Protection Class: Class II
- Voc and Isc Tolerance: ±3%
- Maximum System Voltage: DC1500V
- Maximum Static Loading: Front 5400Pa Back 2400Pa
- Hail Test: 40 mm diameter hail at 25 m/s
- Fire Rating: IEC Class C
